BV Certified Pneumatic Rubber Fender for Marine Docking

продукты

Пневматический резиновый обвайзер

Пневматический морской обвайзер

морская резиновая воздушная подушка

Корабль, запуск подушек безопасности

Раздувные морские воздушные подушки

Морских спасательных надувных подушек

Штепсельная вилка трубы высокого давления резиновая

Свяжитесь с нами

86-157-6394-0460

Свяжитесь сейчас

BV Certified Pneumatic Rubber Fender for Marine Docking

МОК:	1
цена:	650
Стандартная упаковка:	0,51M-4,812м
Срок доставки:	5-8 лет
способ оплаты:	L/C, D/A, D/P, T/T, Western Union, Moneygram
Пропускная способность:	5-8 лет

Подробности Информация

Описание продукта

Подробная информация

Место происхождения

Шаньдун, Китай

Фирменное наименование

Henger

Сертификация

BV, DNV, RL, CCS, ABS, GL, LG

Номер модели

поршень

Выделить:

BV certified marine rubber fender

pneumatic docking fender

marine pneumatic rubber bumper

Описание продукта

Henger Pneumatic Rubber Fender with BV Certification for Durable and Safe Marine Docking Protection

Qingdao Henger Shipping Supplies Co., Ltd is a high-tech enterprise specializing in marine products manufacturing, including marine rubber fenders, marine airbags, navigation marks, and marine buoys. Located in Qingdao, our products are ISO 9001-2008 certified and hold IACS quality authentication from CCS, BV, GL, ABS, and LG.

Inflatable Rubber Fender Introduction

The "Yokohama Type Inflatable Rubber Fender" was developed in 1958. These floating inflatable rubber fenders have evolved alongside ship technology to accommodate increasingly larger vessels like VLCCs, ULCCs, large gas carriers, bulk carriers, and floating structures.

Used worldwide for ship-to-ship (STS) transfer operations and ship-to-dock (STD) operations, these fenders play a critical role in safe ship berthing and mooring. Millions have been supplied globally since their creation.

Key Features:

Constructed with multiple layers of strong tire-cord for pressure and cutting resistance
Design safety factor based on accepted theory and extensive experimentation
Large-size fenders include safety valves for accidental over-pressure protection
Provides completely uniform surface pressure on contact
Particularly suitable for LNG-ship terminals due to low, uniform surface pressure
Special manufacturing techniques and raw material formula enhance kneading-resistance
Each layer treated with specially formulated mucilage for dust removal and enhanced adhesion

Technical Specifications

Fender Size	Compression Amount (60%)	Noumenon Weight (Kg)	Weight with Protective Jacket (Kg)
D (mm) × L (mm)	Reaction (KN)	Energy Absorption (KNm)
500 × 1000	64	6	23
600 × 1000	74	8	28
700 × 1000	137	17	58
1000 × 1500	182	32	82
1000 × 2000	257	45	148
1200 × 2000	297	63	167
1350 × 2500	427	102	220
1500 × 2500	499	134	270
1500 × 3000	579	153	318
1700 × 3000	639	191	380
2000 × 3500	875	308	580
2000 × 4000	1000	352	680
2500 × 4000	1381	663	1064
2500 × 5500	2019	1131	1268
3000 × 5000	2422	1357	1980
3000 × 6000	2906	1293	2400
3300 × 4500	1884	1175	2380

Frequently Asked Questions

"I have ships but don't know how to choose the size of Factory Price Rubber Inflatable Floating Pontoon for Ship Launching Made in China?"

Don't worry. We have more than 20 years' experience. Please provide your ship information, and we can suggest suitable sizes for you.

"What's your MOQ?"

Our minimum order quantity is 1 piece.

"What's your warranty period?"

Our warranty period is 2 years. We will repair or replace products if quality issues are confirmed to be our responsibility.
